Description
The Dynaudio Acoustics M3F is a three-way main monitor for medium-size film and television post-production studios, designed to stand behind the screen. Its tall, narrow cabinet keeps the footprint small and leaves more room in the theater. With Dynaudio subwoofers and surrounds, the M3F forms an immersive system for Dolby Atmos Home Entertainment 7.1.4 and 9.1.4 and for full theatrical Atmos. It covers 35 Hz to 20 kHz and reaches 120 dB at 2 meters.
Drivers and Crossover
Two 300 mm MSP (magnesium silicate polymer) woofers with 100 mm ferrofluid-cooled voice coils handle the bass. Two 170 mm MSP midrange drivers with 75 mm voice coils cover the middle, and a D260H 28 mm soft dome in a short waveguide handles the top. A high-power passive crossover links the midrange and tweeter, and the system is driven as an active two-way, from Dynaudio's DA-series amplifiers with onboard DSP or from DCA-series amplifiers with analog filter cards.
Features
- Built for placement behind the screen
- Small footprint for medium-size dubbing stages
- Two 300 mm MSP woofers with 100 mm ferrofluid-cooled voice coils
- Two 170 mm MSP midrange drivers and a D260H soft dome tweeter in a short waveguide
- 3-way hybrid design: active split for the woofers, passive network for midrange and tweeter
- Suited to Dolby Atmos Home Entertainment 7.1.4 and 9.1.4 and full theatrical Atmos systems
- Black textured paint finish
Specifications
- Application: Post-production and music
- Type: 3-way hybrid
- Frequency response: 35 Hz to 20 kHz
- Maximum SPL: 120 dB at 2 m
- Crossover frequencies: 250 Hz and 2500 Hz
- Total harmonic distortion: 1% at 90 dB
- Recommended amplifier power: Two channels per speaker, 500 to 1000 W per channel
- Recommended amplifiers: Dynaudio Acoustics DA40 DSP, DCA800 (with filters)
- Tweeter: 28 mm soft dome in short waveguide (D260H)
- Midrange: 2 x 17 cm MSP
- Woofers: 2 x 30 cm MSP
- Dimensions (H x W x D): 1300 x 520 x 400 mm (51.2 x 20.5 x 15.7 in)
- Weight: 62 kg (136.7 lb)
- Finish: Black textured paint
