Description
The Voodoo Lab Pedal Power 3 Plus expands the Pedal Power 3 platform to twelve galvanically isolated 500 mA outputs while keeping the hybrid DC transformer design, linear regulation, and 100-240VAC international operation. Ten outputs supply 9V; two are switchable between 9V and 12V. Optional voltage-doubler cables combine outputs for 18V or 24V pedals.
Each output can feed power-hungry DSP effects without starving sensitive analog pedals on the same board. That wide per-output current budget is what makes the 3 series a practical single-supply solution for mixed boards that used to need two adapters or a daisy chain.
Expansion
X-LINK ports add Pedal Power X4 or X8 expanders, or power high-current 12V devices, without a second AC cable. Use the Plus when the board already outgrows eight outputs but you still want one IEC inlet and the same quiet hybrid architecture as the Pedal Power 3.
Specifications
- Outputs: 12 isolated (10x 9V 500 mA, 2x 9V/12V 500 mA)
- Design: Hybrid DC transformer, linear regulation, multi-pole filtering
- Input: IEC, 100-240VAC 50/60 Hz
- Expansion: X-LINK ports
- 18V/24V: Via optional voltage doubler cable
- Dimensions: 7 x 3.4 x 1.5" (178 x 86 x 38 mm)
- Weight: 1.0 lb (0.45 kg)
In the Box
- Pedal Power 3 Plus
- PPPK-12 standard polarity DC cable pack
- Detachable IEC power cord
