Description
The Voodoo Lab HEX is a compact true-bypass six-loop audio switcher. Place one unit on a rack shelf or under most Pedaltrain boards, or rack two units in a single 19" space with the optional HEX rackmount bracket (BS) for twelve loops. Gold-contact relays sealed in nitrogen keep the signal pure no matter how many effects sit in the loops.
Loop 1 is fully independent for A/B switching, amp channel select, or remote tap tempo. Loops 2 through 6 are series-wired for conventional pedal-chain switching. Instantly recall preset effect combinations via MIDI from a Ground Control Pro or any MIDI controller instead of tap-dancing across the board.
Signal Path
A Quiet Switching output buffer kills pops and clicks and preserves tone on long cable runs to the amp. Unused pedals stay completely out of the path when their loops are bypassed. Powers from any Pedal Power 9V DC output. Handmade in the USA.
Specifications
- Loops: 6 true-bypass (Loop 1 independent; Loops 2-6 series)
- Switching: Gold-contact relays sealed in nitrogen
- Control: Front-panel buttons, MIDI In/Out
- Power: 9-12V DC, 100 mA, 5.5 x 2.1 mm center-negative (not included)
- Dimensions: 8.5 x 2.9 x 1.75" (216 x 74 x 44 mm)
- Weight: 1.1 lb (0.50 kg)
- Origin: Handmade in the USA
- Warranty: 5 years
In the Box
- HEX audio loop switcher
