MP-800U SD/USB Player With Bluetooth + FM

Ideal for restaurants, hotels, venues, and studios, the TASCAM MP-800U is a rack mounted SD-card and USB media player with an integrated FM tuner and a USB DAC functionality. With balanced XLR and unbalanced RCA outputs, you can connect a variety of professional and consumer audio devices.

The MP-800U supports MP3, AAC, and WAV audio playback from USB flash drives and SD/SDHC/SDXC cards up to 512GB. The unit features USB-A, USB-C, and 3.5mm TRS headphone connections on the front panel. Also on the front panel are useful controls including 10 numerical keys for track selection and functions, Multi Jog knob, ±16% pitch adjustment, transport controls, and more. Useful functions include Auto Cue, Auto Ready, Incremental Play, and a panel-lock feature. Each output gets its own level adjustment. Several optional addons are available for enhanced functionality, including the IF-E100 expansion card, the AK-BT2 Bluetooth adapter, and the RC-20 controller for playback control of up to 20 tracks.

Versatile Playback

The MP-800U offers multiformat playback via its front-panel SD-card slot (SD, SDHC, and SDXC supported) and USB flash drive port. Compatible file types include WAV, MP3, and AAC. The MP-800U can support SDXC and USB drives up to 512GB in size.

Bluetooth and USB DAC Made Easy

With the optional AK-BT2 Bluetooth adapter, the MP-800U handily streams Bluetooth audio into any installation. Plus, its USB DAC lets you connect any USB equipped device—such as a laptop, smartphone, or tablet—via the front-panel USB-C port, enabling additional playback options like accessing music libraries on computers.

Tune In with FM

The MP-800U features a built-in FM tuner, providing easy access to radio broadcasts. Its dedicated tuner output, via unbalanced RCA connectors, allows seamless integration with any audio system. Easily recall up to twenty user-preset channels from either the front panel or the optional remote control.

Flexible Outputs

Equipped with balanced and unbalanced outputs, the MP-800U can integrate quickly and easily into a variety of audio systems. With two output level controls—one for XLR, RCA, and headphone outputs combined, and another for independent tuner attenuation—this media player delivers smooth and precise level adjustments.

Professional Playback Functions

Pro-level playback is at the core of the MP-800U. Power-on-Play automatically starts playback at startup, while fade-in / fade-out ensures smooth track transitions. Auto-Cue, Auto-Ready, and Incremental Play functions keep your playlists primed, Key Original alters speed without changing pitch, while pitch control adjusts both tempo and key.

RC-20 Controller

Pairing the MP-800U with the optional RC-20 controller allows direct playback start of up to 20 tracks. The rear-panel Control I/O ports also enable fader start/stop integration with an audio mixer.

Specifications

PerformanceFrequency Response20 Hz to 20 kHzDynamic Range95 dB (Playback)Max Output Level+4 dBu (Balanced)-10 dBV (Unbalanced)I/O ImpedanceXLR Output:100 Ohms (Balanced)RCA Output:210 Ohms (Unbalanced)Signal to Noise Ratio95 dBMaximum Sampling Rate48 kHz / 24-Bit (PCM)Bit DepthUp to 24-BitBit Rates32 to 320 kb/s + VBR

Performance

20 Hz to 20 kHz

95 dB (Playback)

+4 dBu (Balanced)-10 dBV (Unbalanced)

XLR Output:100 Ohms (Balanced)RCA Output:210 Ohms (Unbalanced)

95 dB

48 kHz / 24-Bit (PCM)

Up to 24-Bit

32 to 320 kb/s + VBR

ConnectivityAudio I/O2x XLR 3-Pin Male Balanced Line Output2x RCA Female Unbalanced Line Output2x RCA Female Unbalanced Aux Output1x 1/8" / 3.5 mm TRS Female Headphone Output1x F-Type AM/FM Antenna OutputVideo I/ONoUSB I/O1x USB-A (External Memory)1x USB-CNetwork I/ONoControl I/O3x 1/8"/3.5 mm (Remote)BluetoothNo

Connectivity

2x XLR 3-Pin Male Balanced Line Output2x RCA Female Unbalanced Line Output2x RCA Female Unbalanced Aux Output1x 1/8" / 3.5 mm TRS Female Headphone Output1x F-Type AM/FM Antenna Output

No

1x USB-A (External Memory)1x USB-C

No

3x 1/8"/3.5 mm (Remote)

No

CompatibilityAudio File FormatsAAC, MP3, WAVMax Supported Storage CapacityUSB, SD: 512 GB (4 GB File Size)Supported File SystemsFAT16, FAT32, exFATMulti-Channel Audio DecodingNoDigital Media SlotSD, SDHC, SDXC

Compatibility

AAC, MP3, WAV

USB, SD: 512 GB (4 GB File Size)

FAT16, FAT32, exFAT

No

SD, SDHC, SDXC

GeneralPower Consumption14 WInput Power100 to 240 VAC, 50 / 60 HzOperating Conditions32 to 104°F / 0 to 40°CDimensions19.0 x 11.8 x 1.8" / 48.3 x 30.0 x 4.6 cmWeight6 lb / 2.7 kg

General

14 W

100 to 240 VAC, 50 / 60 Hz

32 to 104°F / 0 to 40°C

19.0 x 11.8 x 1.8" / 48.3 x 30.0 x 4.6 cm

6 lb / 2.7 kg
