Tascam CA-XLR2d-AN XLR Microphone Adapter for Cameras (3.5mm Analog)

The Tascam CA-XLR2d-AN is an XLR microphone adapter that brings professional audio to virtually any DSLR or mirrorless camera with a 3.5 mm external mic input. Developed in collaboration with Canon, FUJIFILM, and Nikon, the CA-XLR2d features HDDA mic preamps, 48V phantom power for condenser microphones, and a high-performance A/D converter for clean, low-noise recordings.

This analog kit connects to the camera via the included 3.5 mm stereo mini cable and is powered by two AA batteries. Two balanced XLR/TRS combo inputs accept shotgun mics, dynamic mics, condenser mics, or line-level signals, while a 3.5 mm unbalanced input supports lavalier, wireless, and plug-in power microphones. The output jack doubles as a headphone monitor for real-time audio checking in the field.

Key Features

• Two XLR/TRS combo inputs with HDDA preamps and 48V phantom power
• 3.5 mm stereo mini input with plug-in power (2.7V)
• Attenuation settings: 0 dB / 20 dB / 46 dB
• Low-cut filter: Off / 80 Hz / 220 Hz
• Limiter and auto-level functions
• Per-channel overload indicators
• Cold shoe mount for camera attachment
• Compatible with cameras from Canon, Nikon, Sony, Panasonic, and others via 3.5 mm input

Specifications

• Gain range: 66 dB
• Maximum input level (XLR/TRS): +24 dBu
• Output level: 0.29 Vrms (camera mode, fixed) / 0.5 Vrms (headphone mode, max)
• Headphone impedance: 16 to 250 Ohm
• Power: 2x AA batteries (alkaline, NiMH, or lithium)
• Power consumption: 2.0W maximum
• Dimensions (W x H x D): 3.47 x 4.69 x 4.33 in / 88.2 x 119.1 x 110.0 mm (excluding protrusions)
• Weight: 12.6 oz / 357 g (with battery holder, excluding batteries)
• Operating temperature: 32 to 104 F / 0 to 40 C

In the Box

• CA-XLR2d unit
• CA-AK1-AN cold shoe mount adapter (attached)
• Battery holder
• Mic holder (attached)
• 3.5 mm stereo mini cable
• Quick guide
