Shure MXWNDX2 2-Channel Dante Network Director

Overview

The Shure MXWNDX2 is a 2-channel Dante network director for the Microflex Wireless system. It provides PoE power to MXW access points and charging stations while managing Dante audio routing, device discovery, and system configuration — serving as the central network switch for MXW installations.

Key Features

• Powers connected MXW devices: Provides PoE to access points and charging stations from one central unit
• 10/100 Mbps networking: Managed switch for standard MXW deployments
• Centralized management: Audio routing, device discovery, and channel assignment from one interface
• MXW system hub: Central control point for all connected MXW devices
• Web-based configuration: Full system management via browser interface

Specifications

• PoE ports: 2 × RJ-45 with PoE (802.3af/at)
• Uplink ports: 2 × RJ-45 (10/100) for network backbone connection
• Network speed: 10/100 Mbps
• Dante channels: Up to 8 (2 access points × 4 channels each)
• PoE budget: 60 W total
• Power: IEC AC (100–240 VAC, 50/60 Hz)
• Dimensions: 216 × 168 × 44 mm (8.5" × 6.6" × 1.7")
• Weight: 1.4 kg (3.1 lb)

In the Box

• MXWNDX2 network director
• IEC power cable
• Mounting hardware
