Shure MXA902 Integrated Conferencing Ceiling Array (White, 60 cm Tile, Dante)

Overview

The Shure MXA902W-S-60CM is an integrated conferencing ceiling array that combines a ceiling array microphone, IntelliMix DSP, and loudspeaker in a single device sized for 595 × 595 mm (23.4" × 23.4") for 60 cm metric grid ceiling tile grids. It provides complete conference room audio — both microphone pickup and far-end playback — from one PoE+ network connection.

Key Features

• All-in-one ceiling conferencing: Microphone array + DSP + loudspeaker in a single device
• Automatic coverage: Self-adjusting pickup zones adapt to room occupancy
• Integrated IntelliMix DSP: AEC, noise reduction, AGC, and de-reverb — no external processor needed
• Built-in loudspeaker: Far-end audio playback without external speakers

Specifications

• Microphone: Ceiling array with automatic coverage technology
• DSP: IntelliMix (AEC, noise reduction, AGC, de-reverb, compressor/limiter)
• Loudspeaker: Integrated full-range driver
• Audio outputs: Dante (multiple channels)
• Room coverage: Up to 6.1 × 6.1 m (20 × 20 ft)
• Power: PoE+ (802.3at)
• Tile size: 595 × 595 mm (23.4" × 23.4") for 60 cm metric grid
• Weight: 5.9 kg (13 lb)
• Color: White

In the Box

• MXA902 integrated ceiling array
• Tile bridge support rails
• Ethernet cable
