Description
Overview
The Shure MX180/N is a miniature electret condenser lavalier microphone housing sold without a cartridge. It accepts all Microflex R-series interchangeable capsules (R183B omnidirectional, R184B supercardioid, R185B cardioid) for versatile pattern selection.
Key Features
- Interchangeable cartridges: Works with R183B, R184B, R185B capsules
- Ultra-compact: 22 mm × 12 mm housing, 1.7 g
- Rotatable tie clip: 90° increments for flexible positioning
Specifications
- Type: Electret condenser (cartridge sold separately)
- Frequency response: 50 Hz – 17,000 Hz
- Output impedance: 150 ohms (180 ohms actual)
- Power: 11–52 VDC phantom, 2.0 mA
- Connector: TA4F (4-pin mini) to XLR via in-line preamp
- Cable: 1.2 m (4 ft)
- Dimensions: 22 mm × 12 mm (0.85" × 0.46")
- Weight: 1.7 g (0.06 oz)
In the Box
- MX180/N housing (no cartridge)
- In-line belt-clip XLR preamp
- Pivoting tie clip
- Dual-mic tie clip
- Snap-fit foam windscreen
