Shure AD8C 8-Port Antenna Combiner for Axient Digital PSM (DC Power)
Variant
Talk to our Experts
Talk to our Experts
Have questions about this product? Our team is here to help!
- Call us: (647) 953-1559
- Email: contact@blackoutaudio.com
- Live Chat: Monday-Friday 12:30pm to 7:30pm
Shipping, Returns & Financing
Orders above $199 qualify for Free Standard Shipping.
For international shipping, please request a quote through the contact form.
| Province | Standard Shipping | Express Shipping |
|---|---|---|
| ON | $19 | $39 |
| QC, MB | $29 | $69 |
| Other | $39 | $119 |
Payment & Financing Options
We accept credit and debit cards, Apple Pay, Google Pay, Shop Pay, and PayPal.
Affirm financing is available for most products. To access flexible payment options, select Shop Pay when checking out. Please note that order cancellations or refunds are not available for financed purchases.
Description
Overview
The Shure AD8C (DC) is a full-rack 8-port antenna combiner for the Axient Digital PSM system with DC power input for redundant or battery-backed deployments. It combines RF outputs from multiple ADTD/ADTQ transmitters to shared antenna(s), supporting up to 32 WMAS channels in 8:1 mode or 2× 16 channels in dual 4:1 mode.
Key Features
- DC power for redundant power configurations
Specifications
- Inputs: 8× BNC (from ADTD/ADTQ transmitters)
- Outputs: 1–2× BNC (to antenna)
- RF range: 470–960 MHz
- Max combined channels: 32 (8:1 mode) / 2× 16 (dual 4:1 mode)
- Network: Ethernet (RJ45)
- Power: DC (4-pin XLR)
- Format: Full-rack (1RU)
- Dimensions: 44 × 482 × 385 mm (1.7 × 19.0 × 15.2 in)
- Weight: 3.9 kg (8.6 lb)
In the Box
- AD8C antenna combiner (DC variant)
- DC power cable
- Rack-mount hardware
- Quick Start Guide
