Seymour Duncan TBPR-1b P-Rails Humbucker Pickup (Trembucker Bridge, White)
Position
Color
Talk to our Experts
Talk to our Experts
Have questions about this product? Our team is here to help!
- Call us: (647) 953-1559
- Email: contact@blackoutaudio.com
- Live Chat: Monday-Friday 12:30pm to 7:30pm
Shipping, Returns & Financing
Orders above $199 qualify for Free Standard Shipping.
A few orders are not eligible: items that need specialty shipping (certain cases, stands and other gear that requires special handling), and orders shipping to Newfoundland and Labrador, the Northwest Territories or Nunavut.
Carriers sometimes charge far more for oversized freight to certain locations. In that rare case, we pay most of the extra and ask you to cover a small part.
For international shipping, please request a quote through the contact form.
| Province | Standard Shipping | Express Shipping |
|---|---|---|
| ON | $19 | $39 |
| QC, MB | $29 | $69 |
| Other | $39 | $119 |
Payment & Financing Options
We accept credit and debit cards, Apple Pay, Google Pay, Shop Pay, and PayPal.
Affirm and Sezzle financing are available for most products. For Affirm, select Shop Pay when checking out. Please note that order cancellations or refunds are not available for financed purchases.
Sezzle: eligible customers can split a purchase into 4 interest-free payments over 6 weeks. Approval and payment terms depend on the purchase amount and an eligibility check, may not be available in all provinces or territories, and are shown at checkout. Payment options are provided through Sezzle. For more information, please see sezzle.com/how-it-works.
Affirm: eligible customers can pay over time in monthly instalments. Your rate and available terms depend on an eligibility check based on creditworthiness, your purchase amount, and applicable provincial limits, and may not be available in all provinces or territories. Actual terms, the payment schedule, and any required down payment are shown at checkout. Payment options are provided through Affirm Canada Holdings Ltd. For more information, please see affirm.com/how-it-works.
Description
P-Rails is a full-size humbucker that splits to either a real P90 or a single-coil Rail pickup, so one pickup gives humbucker, P90 and Strat-style tones. With both coils on, the mismatched coils give a full, expansive humbucker sound. The P90 coil alone is fat, and two Rail coils used together sound like positions 2 and 4 on a Strat. It suits country, pop, surf, jazz, blues, classic rock and heavy rock.
This is the bridge model in Trembucker spacing. Its wider pole spacing lines up under the strings on guitars with a tremolo or a wide-spaced hardtail bridge, where the low E to high E distance over the bridge pickup is 2 inches or more, so it suits F-spaced bridges and trems. Use a 2-way switch (push-pull or mini toggle) for humbucker and P90 sounds, or a 3-way on-off-on switch to add the Rail coil. The switch is sold separately. This version is white.
Features
- Humbucker that splits to a P90 or a single-coil Rail
- Mismatched coils for a full humbucker sound
- Wired in parallel, gives a P.A.F.-style humbucker tone with less phase cancellation than a standard parallel humbucker
- Two alnico 5 bar magnets
- 4-conductor lead wire for all wiring options
- Vacuum wax potted for squeal-free operation
- Hand built in Santa Barbara, California
Specifications
- Model: TBPR-1b P-Rails
- Type: Passive humbucker, splits to P90 or Rail single coil
- Position: Bridge
- Spacing: Trembucker (F-spaced)
- Strings: 6
- DC resistance: 19.3k
- Magnet: Alnico 5, two bars
- Cable: 4-conductor shielded
- Color: White
In the Box
- P-Rails Trembucker bridge pickup
- Wiring schematic
- Mounting screws
