RTS KP-4016 16-Key Keypanel with DSP (A5F, 1U)
Talk to our Experts
Talk to our Experts
Have questions about this product? Our team is here to help!
- Call us: (647) 953-1559
- Email: contact@blackoutaudio.com
- Live Chat: Monday-Friday 12:30pm to 7:30pm
Shipping, Returns & Financing
Orders above $199 qualify for Free Standard Shipping.
For international shipping, please request a quote through the contact form.
| Province | Standard Shipping | Express Shipping |
|---|---|---|
| ON | $19 | $39 |
| QC, MB | $29 | $69 |
| Other | $39 | $119 |
Payment & Financing Options
We accept credit and debit cards, Apple Pay, Google Pay, Shop Pay, and PayPal.
Affirm financing is available for most products. To access flexible payment options, select Shop Pay when checking out. Please note that order cancellations or refunds are not available for financed purchases.
Description
OMNEO Open Media Networking Standard
The new KP-Series is future-proof and so is your communication. The unparalleled flexibility features automatic hardware recognition plus the technology of OMNEO, so you get full backward compatibility and easy scalability.
Full IP Connectivity and TCP-IP Layer 2 & 3 Compatibility
Out with the old and in with the more intuitive. The new design and an enhanced user interface enable easier understanding and improved operation. The software provides simple and intuitive navigation of menus, with the most commonly used features easily accessible.
Advanced Signal Processing and AD/DA
Get high-quality audio transmission every time. The new keypanel family features two echo cancellation modes, plus quick AD/DA conversion ensuring ultra-low latency and reducing noise, echo, delay and other malfunctions found in older technologies.
User-Friendly, High-Res Color Display
Get high quality, inside and out. The new KP-Series keypanels feature a unified design, including color, contrast, resolution and viewing angle for complete communication harmony. Plus, multiple controls through ergonomically-designed levers.
Backward compatibility
All KP-Series keypanels are compatible with older technologies such as analog audio in USOC and 568-B connector formats.
Enhanced navigation menus
Optimized for ease of use.
Front panel headset connector
Field-swappable, making it simple to change the default 5-pin XLR (6-pin compatible) headset connector with a 4-pin XLR headset connector, as needed.
Specifications
- Active Area: 120.10mm (wide) x 18.77mm (high)
- Dot Resolution: 576 x 90 pixels
- Color Resolution: 16-bit (64K) RGB color
- View Angle: 80 degrees (typical; all directions)
- AC Input: 100 - 240VAC 50/60Hz
