Description
The Royer R-12 Matched Pair is two R-12 active figure-8 ribbon microphones, supplied by Royer Labs as a matched set for stereo recording. Each mic uses the 2.5-micron aluminum ribbon from the R-121 and runs on 48 V phantom power, with output comparable to a studio condenser. Switchable -15 dB pads and 100 Hz high-pass filters let the pair handle loud drum overheads and guitar amps as well as quiet acoustic sources.
Stereo Setups
Two figure-8 mics give you a Blumlein pair crossed at 90 degrees, or a mid-side array, where recording mid and side on separate tracks lets you set the stereo width at mixdown. Royer's manual also suggests a spaced pair over the bass and treble strings of a piano, an X-Y pair just outside the open lid, and a pair 4 to 6 feet above a drum kit. The low output impedance of the active electronics suits long cable runs on live stages.
Features
- Two R-12 active ribbon microphones, sold as a matched pair
- Figure-8 pattern suited to Blumlein and mid-side stereo
- Active ribbon microphone powered by 48 V phantom
- Same 2.5-micron ribbon element as the R-121
- Output level comparable to a studio condenser microphone
- Switchable -15 dB pad placed ahead of the electronics
- Switchable 100 Hz high-pass filter, 6 dB per octave
- Handles over 160 dB SPL at 1 kHz
- Self-noise under 16 dB
- Three-layer windscreen and internally shock-mounted transducer
- Low output impedance for long cable runs
Specifications
- Quantity: 2 microphones, matched pair
- Operating principle: Electrodynamic pressure gradient with active electronics
- Polar pattern: Figure-8
- Element: 2.5-micron aluminum ribbon
- Magnets: Rare earth neodymium (grade 52)
- Frequency response: 30 Hz to 15 kHz, +/- 3 dB
- Sensitivity: -36 dB (re. 1 V/Pa)
- Self-noise: Under 16 dB
- Pad: -15 dB, switchable
- High-pass filter: 100 Hz, 6 dB per octave, switchable
- Maximum SPL: Over 160 dB at 1 kHz, over 135 dB at 30 Hz
- Output impedance: 200 ohms, balanced
- Rated load impedance: 1 kilohm minimum
- Output connector: 3-pin male XLR (pin 2 hot)
- Power: 48 V phantom, 4 mA
- Dimensions: 209.5 mm (8 1/4 in) long including mounting base, 35 mm (1 3/8 in) wide
- Weight: 462 g (16.3 oz)
- Warranty: 10 years on materials, workmanship and finish to the original owner; first re-ribbon free within one year
