Dynacord VZX-8 8-Zone Audio Processor

$2,199.00 Free Shipping
Found a better price? We'll match it.
SKU: VZX-8-US
2+ In Stock at Shipping Centre
Ships in 1-2 business days. No backorder delays.

Free shipping on most orders above $199

Purchase with Apple and Google Pay

Test gear at our store

Free shipping on most orders above $199

Purchase with Apple and Google Pay

Test gear at our store

Free shipping on most orders above $199

Purchase with Apple and Google Pay

Test gear at our store

Free shipping on most orders above $199

Purchase with Apple and Google Pay

Test gear at our store

Authorized Dealer
Track Your
Order
1-Year Manufacturer Warranty
Blackout Audio storefront
Blackout Audio
Google Reviews
Reviewer
"You can tell they really care." Read
Reviewer
"Welcoming but also super professional" Read
5.0 Read All Reviews
Buy With Confidence
Authorized Dealer
Blackout Audio storefront
Blackout Audio
Google Reviews
Reviewer
"You can tell they really care." Read
Reviewer
"Welcoming but also super professional" Read
5.0 Read All Reviews
Track Your
Order
1-Year Manufacturer Warranty
Buy With Confidence

Talk to our Experts

Have questions about this product? Our team is here to help!

Shipping, Returns & Financing

Orders above $199 qualify for Free Standard Shipping.
For international shipping, please request a quote through the contact form.

Province Standard Shipping Express Shipping
ON $19 $39
QC, MB $29 $69
Other $39 $119

Payment & Financing Options

We accept credit and debit cards, Apple Pay, Google Pay, Shop Pay, and PayPal.

Affirm financing is available for most products. To access flexible payment options, select Shop Pay when checking out. Please note that order cancellations or refunds are not available for financed purchases.

Returns

Products can be returned within 14 days of delivery or pickup.

View our full return policy

Description

The VZX-8 8-Zone Audio Processor features 20 processed input sources, 8 processed zone outputs and advanced DSP features including a Virtual Mixer with AMM, ANC, AGC, EQ with FIR, and more. Loudspeaker presets for Electro-Voice and third-party loudspeakers allow installers to instantly maximize system performance.

Features

  • 20 processed input sources including 8 balanced Mic/Line inputs
  • Full Matrix DSP: input EQ, compression, AGC, Noise Gate, FX, room EQ, speaker EQ with FIR and more
  • Virtual Mixer with Automixer (AMM) and FX available for live mixing on any zone
  • 32 GB MicroSD card included for storing music, messages and configuration files
  • Compatible with SONICUE speaker databases for EV Loudspeakers and more: maximize the performance of your system, instantly
  • 2 x RJ45 Accessory ports work reliably with cable lengths up to 1640 feet (500M) per port, allowing 16 devices total
  • Add VCS-8 Call stations and VWP wall panel controllers with display for level, zone, source control to complete your system

Specifications

General
Compatibility
Dynacord VZ
Inputs/Outputs
Audio I/O
8x RCA Input (Aux)
8x Block Input
8x RCA S/PDIF Input (4 if mono 8 if stereo)
2x RJ45 Input (Accessory)
1x Block Input (EMG Override)
12x Block Output
Media/Memory Card Slot
Single Slot: SD/SDHC [32 GB Maximum]
Internal Storage
300 MB
Inputs
20 x Total Processed Sources
8 x Mic/Line Inputs (Euroblock)
4 x RCA Inputs (Summed mono)
8 x Mono Digital
4 x Stereo Digital
2 x RJ45 Accessory Ports
1 x EMG Override Inputs (Euroblock)
Outputs
8 x Total Processed System Zones
8 x Line Outputs (Euroblock)
2 x RJ45 Line Out 1-4/5-8 For Use with V-Series Amplifiers (AES72-1E)
Data Storage
Recording Media Types Supported: MicroSD, MicroSDHC, MicroSDXC
Recording Media Storage Formats Supported: FAT32, exFAT (2TB Maximum)
Auto-backup (Configuration File): Via MicroSD Card (Included)
Configuration Copy/Paste: Via MicroSD card (Included)
Media Player: Playlists, Play/Pause, Shuffle
Message Player: Wall panel Controller, Call Station or GPIO Triggers
Maximum Output Level
15.78 dBV / 18.0 dBu
Output Level
3.78 dBV / 6 dBu (Nominal)
Supported Cable Types
24 - 16 AWG
Phantom Power
+48V / 10 mA, Switchable per Analog Input
Gain
0 dB - 60 dB
Maximum Input Level
15.78 dBV / 18 dBu (0 dB gain)
Input Impedance
3.3 ohms
Digital Input
+18 dBu for 0 dBFS (reference level)
Sample Rate
48 kHz
THD + N
< 0.003% at 0 dBu Input/Output with -1 dB Gain at 1 kHz
Frequency Response
20 Hz to 2 kHz (± 0.5 dB)
Signal to Noise Ratio
> 115 dB (A-Weighted, Analog Input B)
> 115 dB (A-weighted, Analog Output)
> 110 dB (A-weighted, Analog Input to Analog Output)
Equivalent Noise Level
< -125 dB (20 Hz to 20 kHz, A-Weighted) (Input)
Crosstalk
< -80 dB (Maximum Mic Gain)
< -100 dB All Other Inputs/Outputs (1 dB below max. at 1 kHz)
CMRR
> 55 dB (0 dB Gain)
> 85 dB (30 dB Gain) (at 1 kHz, Nominal Level)
Power
Power Source
AC Input (Included)
AC Input Power
100 to 240 VAC, 50 / 60 Hz
Power Consumption
55 W (Maximum)
Physical
Mounting
Front: 4x Rack
