Description
The TGX System Rack is a modular solution designed and built for touring professionals by touring professionals.
The 10U TGX system rack is preconfigured with three TGX20 DSP amplifiers plus two independent network switches for glitch-free operation and offers a variety of professional features such as integrated sliding rack doors, customizable I/O options, and a reversible mounting for the power distribution. The TGX system racks can be vertically stacked and locked together to give up to 180kW of output power in the same compact footprint as a conventional amplifier rack.
Features
- Preconfigured system rack including three TGX20 DSP amplifiers, power distribution, input and output interfaces and network redundancy
- Power distribution mountable either on front or rear*
- Integrated rack sliding doors
- Stackable on a single dolly
Specifications
Color |
Black |
Amplifier channels |
12 |
Balanced line level |
Input / AES3: 4 / 2 XLR f (Neutrik) Out / AES3: 4 / 2 XLR m (Neutrik) |
Amplifier outputs |
3 x 2 NL8 (Neutrik speakON) |
Ethernet Connections |
2 x 2 RJ45 (Neutrik etherCON) Primary and secondary |
Network switches |
Managed GB switches, Layer-3, 10-port, pre-configured for OMENO/Dante |
Mains Power Inlet |
EU: CEE 32A-3phase-230/400V US: NEMA L21-30, 208 VAC |
Ambient Temperature Limits |
40 to 105 Degree F (5 to 40 Degree C) |
Payload (Maximum) |
156 lb (70.7kg) |
Dimensions |
With dolly board: 23.6 x 28.2 x 25.7" (600 x 718 x 655mm) Without dolly board: 23.6 x 22 x 25.7" (600 x 558 x 655) |
Weight |
With dolly board: 272.9 lb (123.8kg) Without dolly board: 248.7 lb (112.8kg) System rack empty with Dolly Board: 116.9 lb (53kg) without dolly board: 92.6 lb (42kg) |
