Description
The Apogee Symphony Studio 8x16 is a 1U rackmount USB-C audio interface with eight microphone/line inputs and sixteen line outputs, the largest configuration in the Symphony Studio range. Sixteen outputs cover a 9.1.6 Dolby Atmos array, so one rack space handles both tracking and immersive monitoring.
Inputs and Outputs
Eight mic/line inputs with up to 75 dB of preamp gain and +48V phantom power handle multi-microphone tracking sessions. Sixteen balanced line outputs on DB25 drive immersive monitor arrays up to 9.1.6, and two headphone outputs can be addressed independently.
Onboard DSP
Every input has a DSP channel strip with EQ and dynamics that runs on the interface, so you can monitor or record processed signal without plug-in latency. The outputs have their own DSP for Room EQ, per-output delay for speaker alignment, and bass management, which matters when the monitor setup is a surround or immersive array rather than a single stereo pair.
Specifications
- Analog inputs: 8 mic/line
- Analog outputs: 16 line outputs on DB25
- I/O summary: 8 in x 16 out
- Mic preamps: up to 75 dB gain, +48V phantom power
- Conversion: Symphony I/O Mk II grade, 24-bit / up to 192 kHz
- Input DSP: channel strip with EQ and dynamics per input
- Output DSP: Room EQ, delay, bass management
- Immersive monitoring: up to 9.1.6 Dolby Atmos
- Headphone outputs: 2, independently addressable
- Host: USB-C, class compliant (no driver required)
- Power: 90 to 240V AC, internal supply
- Rack size: 1U
- Dimensions: 482.6 x 308 x 44 mm (19" x 12.125" x 1.73")
- Weight: 4.5 kg (10 lb)
In the Box
- Apogee Symphony Studio 8x16
- IEC power cable
- USB-C cable
- Quick start guide
