Description
This is the Apogee Symphony I/O Mk II chassis with Pro Tools HD connectivity and no I/O modules installed. It is the starting point for a custom configuration: choose the analog and digital modules the room needs, or reuse modules you already own.
Chassis and Control
The Symphony I/O Mk II chassis holds Apogee's flagship conversion, a front-panel color touchscreen for input selection, gain, metering, and monitor control at the rack, and two module bays for up to 32 channels. Because the I/O is modular, the same chassis can be re-specified later as the room's channel count changes. Apogee's Symphony Control software mirrors the hardware controls on the computer, and the optional Apogee Control hardware remote adds a physical level knob and assignable buttons.
Connectivity
A Pro Tools HD option card connects the interface over DigiLink to Pro Tools HDX and HD Native systems, so it works as a Pro Tools HD interface without a Thunderbolt host. Input and monitoring settings remain available on the front-panel touchscreen.
I/O Modules
At least one module is required before the chassis can pass audio. Available modules include the 8x8 MP (8 mic/line inputs with digitally controlled preamps and 8 line outputs), the 16x16 SE (16 line inputs and outputs on DB25), and the 2x6 SE (2 analog inputs and 6 analog outputs with AES and optical digital I/O). Two bays can be filled in any combination up to 32 channels.
Specifications
- Installed I/O modules: none, sold separately
- Connectivity: DigiLink for Pro Tools HDX and HD Native
- Conversion: Apogee flagship AD/DA, 24-bit / up to 192 kHz (determined by the installed modules)
- Expansion: two module bays, up to 32 channels per chassis
- Display: front-panel color touchscreen
- Rack size: 2U
- Dimensions: 450 x 292 x 89 mm (17.75" x 11.5" x 3.5"); 482.6 mm (19") wide with rack ears fitted
- Weight: approximately 8 kg (17.6 lb) for the chassis; total weight depends on installed modules
- Power: 90 to 240V AC, 150W internal supply
In the Box
- Symphony I/O Mk II chassis with Pro Tools HD connectivity
- IEC power cable
- Quick start guide
I/O modules, Thunderbolt cables, and DigiLink cables sold separately.
