Description
The Apogee Symphony I/O Mk II 8x8 MP + 8x8 MP is a 2U rackmount multichannel audio interface built on the Symphony I/O Mk II chassis, configured here with two 8x8 MP modules, plus both Thunderbolt and Pro Tools HD connectivity. As delivered it provides 16 analog inputs and 16 analog outputs including 16 mic preamps, running through Apogee's flagship conversion.
Installed I/O Modules
- 8x8 MP: 8 mic/line/instrument inputs with digitally controlled preamps and +48V phantom power, 8 balanced line outputs, plus AES, ADAT, and S/PDIF digital I/O
- A second identical 8x8 MP module fills the other bay, doubling those counts
Connectivity
Thunderbolt and Pro Tools HD cards are both installed, so one unit serves a Mac over Thunderbolt and a Pro Tools HDX or HD Native rig over DigiLink. Rooms that track to Pro Tools HD and mix in a native DAW can switch hosts without re-cabling the analog I/O.
Chassis and Control
The Symphony I/O Mk II chassis holds Apogee's flagship conversion, a front-panel color touchscreen for input selection, gain, metering, and monitor control at the rack, and two module bays for up to 32 channels. Because the I/O is modular, the same chassis can be re-specified later as the room's channel count changes. Apogee's Symphony Control software mirrors the hardware controls on the computer, and the optional Apogee Control hardware remote adds a physical level knob and assignable buttons.
Specifications
- Analog inputs: 16 mic/line across two 8x8 MP modules
- Analog outputs: 16 line across two 8x8 MP modules
- Mic preamps: 16 digitally controlled, +48V phantom power
- Digital I/O: AES, ADAT, and S/PDIF
- Connectivity: Thunderbolt (Mac) and DigiLink for Pro Tools HDX and HD Native
- Conversion: Apogee flagship AD/DA, 24-bit / up to 192 kHz
- Expansion: two module bays, up to 32 channels per chassis
- Display: front-panel color touchscreen
- Rack size: 2U
- Dimensions: 450 x 292 x 89 mm (17.75" x 11.5" x 3.5"); 482.6 mm (19") wide with rack ears fitted
- Weight: approximately 8 kg (17.6 lb) for the chassis; total weight depends on installed modules
- Power: 90 to 240V AC, 150W internal supply
In the Box
- Symphony I/O Mk II 8x8 MP + 8x8 MP with Thunderbolt + Pro Tools HD connectivity
- IEC power cable
- Quick start guide
Thunderbolt, DigiLink, DB25, and network cables sold separately.
