Description
The Pedal Power X4 Expander Kit adds four isolated 9V 500 mA outputs to an existing Voodoo Lab supply that has a 12V high-current output (400 mA or greater), including Pedal Power 3 X-LINK ports. It is the same ultra-compact X4 hardware without an AC adapter, so it draws power from the host supply via the included PPBAR cable and keeps a single AC inlet for the whole system.
Use it when the board outgrows the host's native outputs but you do not want another wall wart. Add a PS1210 adapter separately if you later want to run the expander standalone. Mounts with 3M Dual Lock under crowded boards.
Specifications
- Outputs: 4 isolated (4x 9V 500 mA; total limited by host 12V source)
- Input: 12V DC via included PPBAR from host Pedal Power (no AC adapter included)
- Dimensions: 3.38 x 2.75 x 1" (86 x 70 x 25 mm)
- Weight: 4 oz (0.11 kg)
In the Box
- Pedal Power X4 Expander
- PPBAR 18" 12V input cable
- 2x PPBAR-RS (18") and 2x PPBAR-RS12 (12") DC cables
- 3M Dual Lock mounting tape
